Calculations based on 55℃ according to EN16147
* 5 YEAR WARRANTY SUBJECT TO ANNUAL SERVICE AGREEMENT *
| Model No | KERS COOLBOOST-W230 | KERS COOLBOOST-W300 |
|---|---|---|
| Tank Volume (Litres) | 230 | 300 |
| Cooling Capacity | 1.5kw | 1.5kw |
| Heating Capacity (W) | 2010 | 2010 |
| Max Power Input | 560w | 560w | COP (EN255/3) | 4.5 | 4.5 |
| COP (EN16147) | 3.5 | 3.5 |
| Electrical Connection | 230v/50Hz/1Ph | 230v/50Hz/1Ph | AMP | 10 | 10 |
| Working Pressure | 8 BAR | 8 BAR |
| Max Water Temp (No immersion) | 70℃ | 70℃ | Refrigerant | R513A | R513A |
| Electrical Heater Optional (W) | 1.5kW | 1.5kW |
| Duct Minimum Diameter (mm) | 150mm/220mm x 90mm | 150mm/220mm x 90mm | Max Pressure (Pa) | see fan spec | see fan spec |
| Flow rate minimum (I/s) | 80 | 80 |
| Corrosion Protection | Vacuum enameled | Vacuum enameled |
| Weight (Kg) | 105 | 120 | Dimensions (mm) HxD | 1858 x 668 | 2108 x 668 |
